How to Setup a Bungee for Hydrofoil Towing – DIY Boat Alternative

How to Bungee FoilIntroducing our Bungee 2.0 hydrofoil launching - pulling - towing system.  Lot's of fun, and enough towing power to get us all up on a prone foil board, I weigh about 200 pounds and there was enough pull for me to fly.  The two big additions to our bungee are the hand crank winch for pulling back the bungee and a quick release attachment.

We used a 16 pound anchor I found on craigslist.  Some of the recommendations are at minimum a 25 pound Danforth anchor.  Our bungee in this video ended up being 100 feet, we made our own braiding three lengths of 3/8" thick 100 foot bungee cords.   We winched the bungee back far enough that the anchor gave way a few times.  When it did the anchor would move through the water relatively slowly, maybe 20 feet or so and then settle on the bottom, we still had tension on the bungee but not a very much.  Our setup has enough weight to it that there is little chance of the bungee or anchor from flying back towards us, we felt safe even when the bungee was really tight and we could barely crank it back any further.

We also had an inflatable buoy to let us know where the anchor was and hopefully serve as a barrier if the anchor came loose.  The other function of the buoy was to keep the bungee up and mostly out of the water. My thinking was that a raised straighter pull would help us lift the foil, whereas a downward underwater pull might make it harder.  The buoy also helped other folks on the water see us and our bungee line and go around it.  Using a longer rope (100 feet) between our buoy and the anchor helped the anchor stay put, so the anchor had a more horizontal pull rather than being pulled slightly up.

The trickiest part of our first Bungee test was getting up on the board and staying balanced in he first few seconds while launching the bungee.  Water starting seemed to difficult, so we set a 2x4 board in between two ladders and used this as our "dock" starting platform.  I suspect some kind of floating "dock" would work, maybe an inflatable inter-tube or raft.

One of my motivations for this is to find a human powered affordable way to practice and have fun foil surfing.

These sessions were on a smaller wing (around 120), prior to the winch addition on a bigger wing (160) lift was much easier.  So I suspect a bigger wing on this bungee setup would enable some long rides, and give newbies another way to try foiling.

I hope this helps!

And below is a members only longer version of this how to video, 10 minutes and 10 seconds:

Also available for members are more video tips and info on our setup and some details that allowed us to have more pulls faster and easier:



This content is for members only. Please Log In or Register for access.

Log In Join

Read more

Foil Setup – Angle of Attack and Foot Placement – Surfing

Foil Angle of Attack and Foot Placement for SurfingA video showing how to setup foil Angle of Attack for surfing, and where I put my feet and why. Since adjusting the angle of attack and being very precise with my feet placement my foil surfing has improved big time. I have much more control and I know how to setup my hydrofoil and foot hooks for the conditions - bigger or smaller waves.

I have been having really long rides and breaching way less since setting up my boards this way. Also getting my cutbacks and bottom turns dialed and pumping more. With this improved control I also feel way more confident in a more crowded surf spot.

I am so stoked on foiling and eagerly looking forward to the next swell!

Here is the shorter version of this how to video:



And below is the longer video, 16 minutes and 53 seconds:


This content is for members only. Please Log In or Register for access.

Log In Join

Read more

Soloshot 3 – How to Setup and Operate and Securely Lock

Soloshot 3How to setup the Soloshot 3 so it works 100% of the time.  Below are two videos:  1 – is how to setup, calibrate, and be free of interference.  These methods allowed me to overcome a very low success rate to now having the Soloshot 3 work 100% of the time.

The second video is how I securely lock my Soloshot 3 and tripod when at the beach, extend the battery life, protect  the Soloshot 3 from rain fog wind, and wearing the tag armband.

Read more

Clean Beaches with Renewables – Free and Simple

Clean BeachesA Clean Beaches video I made for SUP the Mag.

I started monkeying around with renewable bamboo because I had some poles collecting dust in my garage.  Building with free bamboo seemed better than ordering another couple hundred dollars worth of carbon tubes.  Now that my eyes are open to building with bamboo, wood, and other plants it’s a no-brainer for me to start building with these materials and stay with it even if…

Read more

DIY Wood Surfboard Rack – How to Video

DIY Wood Surfboard RackOver the years living in several different houses my surfboards also needed a home.  Putting them in the rafters or loft of a garage or shed was quick storage but pulling them out was always a hassle.  So I have made several versions of a wall mounted multi-board rack, and I am stoked with this wood rack I am using now.  I made a video tutorial of how I built this wood rack for SUP the Mag.

I built it around 3 years ago and it has held strong and sturdy.  Purchasing an unlimited board required re-configuring the rack to accommodate this 17 foot board.  It was surprisingly easy to rearrange the rack arms.  I am stoked to report the rack has held the weight of 3 downwind boards, 2 sups, and several shortboards totaling about 140 pounds.

Making a rack out of renewable plants is important to me, and I love the smell of wood in my garage:
